Project details

The following is a table of common O-ring end face seal dimensions for reference only:

Model inner diameter (mm) outer diameter (mm) groove inner diameter (mm) groove outer diameter (mm) depth (mm) width (mm)

4X1.8 1.8 2.4 1.8 2.47 0.254 0.128

5X1.8 1.8 2.9 1.8 2.98 0.315 0.128

6X1.8 1.8 3.4 1.8 3.48 0.375 0.128

7X1.8 1.8 3.7 1.8 3.76 0.405 0.128

7.5X1.8 1.8 4.2 1.8 4.26 0.435 0.128

8X1.8 1.8 4.5 1.8 4.56 0.465 0.128

***********************************************************************************************************
