Import chamfer

The correct groove design can eliminate possible damage and seal failure from the start. Since the O-ring is squeezed during installation, when designing the parts to be contacted during the introduction of the O-ring, there must be specified chamfering and rounding.


Groove design(图1)


The minimum chamfer length Z, as a function related to the diameter of the O-ring section, is listed in the following table: Table 1-1 Import chamfer

Groove design(图2)
