hydraulic o-rings size chart

The size table of hydraulic O-rings is usually formulated based on international standards, with the most commonly used standard being ISO 3601-1:2012, which specifies various sizes and specifications of hydraulic O-rings. These dimension tables include key parameters such as inner diameter (ID), outer diameter (OD), cross-sectional width (CS), and tolerances.

The following are some common examples of hydraulic O-ring sizes in millimeters, but please note that the specific size table may vary depending on the manufacturer and supplier. We suggest that you search for a specific size table or contact the supplier for detailed information based on your specific application and needs.

Standard inner diameter size (ID): Typically ranging from 1 mm to 1500 mm, some common dimensions include:

5 mm

10 mm

20 mm

50 mm

100 mm

Standard Outer Diameter Dimensions (OD): Typically ranging from 3 mm to 1550 mm, some common dimensions include:

7 mm

15 mm

25 mm

55 mm

105 mm

Standard cross-sectional width dimensions (CS): typically ranging from 1 mm to 30 mm, some common dimensions include:

2 mm

5 mm

10 mm

20 mm

Tolerance: The tolerance of hydraulic O-rings is usually specified in the dimension table to ensure sealing performance.

Please note that the size and specifications of hydraulic O-rings may vary depending on the specific hydraulic system and application. Therefore, when selecting hydraulic O-rings, it is best to refer to the size table and specifications provided by the manufacturer to ensure that the sealing components are compatible with your system. In addition, some manufacturers also provide online tools to help users choose the appropriate O-ring size and material.
