hydraulic o-ring size chart

The size table of hydraulic O-rings usually includes various sizes and specifications of O-rings to meet the needs of different hydraulic systems and applications. The following are some common examples of hydraulic O-ring dimensions (usually expressed in inches or millimeters). Please note that this is only an example and does not represent all possible sizes, as the sizes of O-rings vary depending on the specific application requirements:

Example of inch size:

1/4 "x 3/8" x 1/16“

3/8 "x 1/2" x 1/16“

1/2 "x 5/8" x 1/16“

3/4 "x 7/8" x 1/16“

1 "x 1-1/4" x 1/8“

Example of millimeter size:

6 mm x 8 mm x 1 mm

8 mm x 10 mm x 1 mm

10 mm x 12 mm x 1 mm

15 mm x 20 mm x 2 mm

20 mm x 25 mm x 2.5 mm

Please note that these are only examples, and the actual hydraulic O-ring size table may contain more size options. When selecting hydraulic O-rings, you need to consider the inner diameter, outer diameter, and cross-sectional diameter (CS) to ensure compliance with your specific application requirements.

The specific hydraulic O-ring size table can usually be obtained from the O-ring manufacturer, supplier's product catalog, or online resources. If you need a specific size of O-ring, it is recommended to contact the manufacturer or supplier directly. They can usually provide detailed product specifications and size information to help you choose the O-ring that suits your needs.
